Description
Key Features
- Self-Cooling Technology: Eliminates the need for external lubrication systems, reducing contamination risks and simplifying operations.
- Enhanced Dry-Sealing Capability: Proprietary carbon-grade primary rings and silicon carbide mating rings ensure superior thermal conductivity and dry-sealing performance.
- Compact Design: Available in a short seal design (Type S48SC) for ANSI and older API pumps with restricted axial length.
- Retrofitting Ease: Can be easily installed in existing cartridges, simplifying upgrades from liquid-lubricated systems.
- Low Heat Generation: Features tapered mating ring surfaces, optimized face width, and reduced thermal distortion for cooler operation.
- Regulatory Compliance: Meets Maximum Achievable Control Technology (MACT) emission standards, ensuring environmentally safe operations.
Performance Capabilities
- Temperature Range: -29°C to 205°C (-20°F to 400°F)
- Pressure Ratings:
- Dry Operation: 0.35 bar g (5 psig) continuous
- Wet Operation: 69 bar g (1000 psig)*
- Speed: Up to 20 m/s (4000 fpm)
* Maximum containment pressure depends on process fluid properties.
Applications
The ORMG2 is ideal for:
- Dry Running Operations: Reduces hazards associated with buffer fluid contamination and disposal.
- Critical Containment Sealing: Ensures emission control in compliance with strict industrial standards.
- Chemical Processing and Cryogenics: Provides robust sealing in extreme environments.
- Offshore Platforms and Pipelines: Handles harsh conditions with reliable performance.
- Oil Production and Refining: Ensures safe operations in demanding oil and gas settings.
Compatible Fluids
- Condensates
- Heat Transfer Fluids
- Hydrocarbons (Flashing/Non-Flashing)
- LNG/LPG/NGL
- Mild Acids
- Sour Water
Seal Diagram
Dimensional Data
Industries Served
- Automotive: Supports high-speed operations with precision sealing.
- Biofuels: Reliable performance for renewable energy processes.
- Food & Beverage: Provides hygienic and efficient sealing solutions.
- Mining & Minerals: Operates in abrasive and high-pressure environments.
- Oil & Gas: Ensures integrity under extreme pressures and temperatures.
- Power Generation: Perfect for high-performance turbine and boiler systems.
- Pulp & Paper: Handles viscous and challenging fluid applications.
- Sugar Industries: Corrosion-resistant for efficient sealing.
- Cement Plants: Durable in dusty and high-vibration setups.
- Petrochemicals: Reliable sealing for reactors and processing equipment.
- Pharmaceutical: Ensures compliance and precision in sterile conditions.
Why Choose the ORMG2?
- Unmatched Sealing Integrity: Dual seals work in tandem to prevent leaks effectively.
- Advanced Design: Self-cooling technology and thermal management ensure long-lasting performance.
- Simplified Maintenance: Easy retrofitting and low-maintenance design reduce downtime.
- Environmental Safety: MACT-compliant, making it an eco-friendly choice.
- Global Expertise: Trusted by industries worldwide for robust and innovative sealing solutions.
