Applications

The Wave Spring Unbalanced O Ring Seal Type: 901 is specially designed for applications involving:

• Slurry Handling: Isolated wave springs protect against abrasive and corrosive slurries.
• High-Viscosity Fluids: Delivers unmatched sealing performance in media with high viscosity and solid particles.
• Critical Component Protection: A dynamic O-ring ensures the pump sleeve and shaft remain protected from wear and tear.
• Abrasive and Corrosive Media: Handles challenging fluids while maintaining operational integrity.

---

Industries Served

The Type 901 caters to a diverse range of industries, providing reliable and efficient sealing solutions:

1. Biofuels: Ensures consistent operation in biofuel processing systems involving viscous and abrasive materials.
2. Chemical: Ideal for chemical processing plants handling corrosive and polymerizing fluids.
3. Food & Beverage: Hygienic sealing for viscous liquids, syrups, and slurries in food production.
4. Mining & Minerals: Designed for abrasive slurry applications in mineral processing and mining.
5. Oil & Gas: Robust performance in upstream and downstream operations involving challenging fluids.
6. Power Generation: Reliable sealing for power plants handling diverse media.
7. Pulp & Paper: Effective sealing for slurries and high-viscosity media in pulp and paper manufacturing.
8. Petrochemicals: Durable and efficient sealing for petrochemical processing applications.
9. Pharmaceutical: Hygienic, reliable solutions for pharmaceutical manufacturing processes.

---

Operating Parameter

The Type 901 delivers optimal performance under the following conditions:

• Shaft Diameter: 18 to 120 mm
• Pressure: Vacuum to 10 Bar
• Temperature: -20°C to 180°C
• Speed: Up to 25 m/s

---

Materials of Construction

Manufactured using premium-grade materials, the Type 901 ensures compatibility with a wide range of applications:

• Seal Faces: Carbon, Silicon Carbide (SiC), Tungsten Carbide (TC), Aluminum Oxide (AlO2)
• Secondary Seals: NBR, FKM, FFKM, EPDM
• Metal Components: SS-316, SS-304, Hastelloy-C246, Inconel-718

---

Key Features

1. Wave Spring Design: Enhances reliability and durability in high-viscosity and slurry applications.
2. Isolated Springs: Prevents product contact with springs, reducing wear and enhancing longevity.
3. Dynamic O-Ring Elastomer: Provides superior sealing and protection for pump shafts and sleeves.
4. Unbalanced Configuration: Optimized for handling lower-pressure applications effectively.
5. Compact Design: Requires minimal axial and radial space, making it suitable for space-constrained installations.
6. Ease of Installation: Simplified design ensures quick and efficient setup, reducing downtime.
7. Rugged and Reliable: Withstands abrasive and corrosive conditions with consistent performance.

---

Seal Diagram

---

Important Notes

1. Ensure material compatibility with the media for optimal performance.
2. Follow Orbit Fluid Solution LLP’ installation and maintenance guidelines to extend seal life.
3. Consult our technical team for customization or unique application requirements.

---
